Main advantage:
.Servo automatic feeding; Bundle cutting
.5 sets number of different cutting length
.Material piece end pull out function
.PLC touch screen control
. Electronic cutting counter
.No burr, high accuracy
.Right & left clamp
. Vertical slide way up-and-down sawing
| Model | LX-400CNC-H | |
| Main Drive Motor(KM) | YD100L-4/2 380v 2.4/3.7KW 50HZ（Frequency） | |
| Biade Speeds(RPM) | 25/50(Stainless steel） 52/104（Standard） | |
| Saw Blade Size | Diameter(mm) | HSSφ275-φ400 φ450（Special） |
| Pin Holes(mm) | 2×φ11×PCD63 | |
| Max.Clamping Capacity (mm) | 180（Customizable） | |
| Oil Pressure System | Oil pressure(kg/cm2) | 25-35 |
| Hyd.Oil storage capacity(L) | 100 | |
| Net Weight(KG) | 800 | |
| Machine Dimensions(L×W×H)(mm) | 3000*1100*2100 | |
